詳細規格:
|
SPIROMETER INPUT (A1) |
|
|
Range |
±10 cm water |
|
PRESSURE TRANSDUCER INPUT (A2) |
|
|
Range |
1700 mmHg |
|
BNC INPUTS (A3 and A4) |
|
|
Number of inputs |
2 |
|
Input range |
±10 VDC |
|
Resolution |
16 bit |
|
System Noise |
< 1mV p-p |
|
Connector |
BNC |
|
DIN8 TRANSDUCER INPUTS (A5 and A6) |
|
|
Number of inputs |
2 |
|
Input range |
±10 VDC |
|
Resolution |
16 bit |
|
System Noise |
< 1mV p-p |
|
Isolation |
No |
|
Excitation |
±5 VDC, 100 mA |
|
Connectors |
DIN8 |
|
Gain |
Programmable with input resistor |
|
HIGH VOLTAGE STIMULATOR OUTPUT |
|
|
Connectors |
HV Safety |
|
Output range |
0-20 mA |
|
Compliance |
100 V |
|
Max ON time |
10 ms |
|
LOW VOLTAGE STIMULATOR OUTPUTS (S1 and S2) |
|
|
Resolution |
16 bit |
|
Connectors |
BNC |
|
Output range |
±15 VDC at 35 mA |
|
Modes |
Pulse, Train, Constant, Step, Ramp, Triangle, Custom |
|
DIGTAL INPUTS and OUTPUTS |
|
|
Input |
8 independent lines, TTL input, 1 Megohm input impedance, 5 V maximum |
|
Output |
8 independent lines, TTL output level, 24 mA maximum load per line |
|
A/D CONVERTER |
|
|
Sampling speed |
200k Hz aggregate |
|
Interface |
USB 1.1, 2.0, full speed |
|
GENERAL |
|
|
Power |
12 VDC, 1.5 A |
|
Enclosure and Dimensions |
Plastic; 23 cm W, 15 cm D, 6.5 cm H |
|
Weight |
725 g |
|
Warranty |
3 years |
|
Software |
LabScribe recording and analysis software |
