詳細規格:
|
Maximum Load |
3 Kohm (at 50mA) |
|
Compliance Voltage |
Approx. 180V |
|
Output Waveform |
Square Wave |
|
Pulse Width |
0.1 – 99.9 msec |
|
Pulse Interval |
1 – 100 msec |
|
Output Current |
0.1 – 50.0 mA |
|
Output Duration |
0.1 – 10.0 sec |
|
Increasing-Current Level |
0.1 – 10.0 mA/Step |
|
Step Time |
0.1 – 1.0 sec |
|
Display |
3 Digit LED |
|
Operation Mode |
Constant-Current or Step-Up Mode |
|
Power |
Please specify your input voltage when ordering |
|
Dimensions |
W430 x D300 x H130mm |
|
Weight |
Approx. 6.5 kg |
